Gupta, Bhardwaj, and Sharma: Diagnostic utility of thyroid fine needle aspiration cytology using The Bethesda System for Reporting Thyroid Cytopathology: A one year prospective study


Introduction

Thyroid diseases are among the commonest endocrine disorders worldwide. About 42 million people in India suffer from thyroid diseases according to a projection from various studies on thyroid disease.1 Thyroid cancer is the most common endocrine malignancy, constituting 0.1%–0.2% of all cancers in India with an age-adjusted incidence of 1 per 100,000 in males and 1.8 per 100,000 in females.2 Fine needle aspiration cytology (FNAC) is the first line diagnostic procedure for evaluating thyroid lesions. It is a simple, rapid, cost-effective test that provides valuable information about the nature of a thyroid nodule, can effectively distinguish between neoplastic and non‑ne oplastic lesions of the thyroid and permits the triage of patients for follow-up or surgery thus reducing unnecessary surgery for patients with benign disease.3,4

FNAC, however, has certain inherent limitations e.g. it cannot differentiate follicular and Hurthle cell carcinomas from their benign counterparts as it cannot establish the presence of capsular and/or vascular invasion. Also, thyroid FNA suffers from variability in its diagnostic terminology.5 Several classification schemes have been suggested including Papanicolaou Society of Cytopathology, American Thyroid Association and American Association of Clinical Endocrinologist, but none of them have been universally accepted.6,7

Reporting of thyroid FNA specimens should follow a standard format that is clinically relevant in order to direct appropriate management.8 The Bethesda System for Reporting Thyroid Cytopathology (TBSRTC), a six-category scheme proposed by National Cancer Institute at a conference in Bethesda, United States in 2007 represents a major step towards a uniform reporting system for thyroid FNA that facilitates interpretation of thyroid FNA results in terms that are succinct, unambiguous and clinically useful, by pathologists and referring clinicians. Each of the categories has an implied malignancy risk (ranging from 0% to 3% for the benign category to virtually 100% for the malignant category) that links it to a rational clinical management guideline.9,10

The present study was carried out to assess the diagnostic utility of thyroid FNAC using The Bethesda System for Reporting Thyroid Cytopathology.

Materials and Methods

It was a one year prospective study from Nov. 2017 to Oct. 2018 conducted in the Department of Pathology, Government Medical College, Jammu. It included all patients presenting with thyroid swelling referred to this department from various clinical departments of this hospital and from other health care centers. Non-cooperative and morbid patients were excluded from the study.

FNAC was performed using 22-24G needle and 20cc syringe. Smears were prepared; air dried smears were stained with May-Grunwald-Giemsa (MGG) stain and alcohol fixed smears were stained with Papanicolaou (PAP) stain. Stained smears were examined under light microscopy. The adequacy was assessed as per Bethesda criteria and the thyroid fine needle aspirates were classified into the six categories according to The Bethesda System for Reporting Thyroid Cytopathology i.e. Nondiagnostic /Unsatisfactory (ND/UNS), Benign, Atypia of Undetermined Significance/Follicular Lesion of Undetermined Significance (AUS/FLUS), Follicular Neoplasm/Suspicious for Follicular Neoplasm (FN/SFN), Suspicious for Malignancy (SFM) and Malignant categories. The definitions and cytomorphological criteria as described in The Bethesda System for Reporting Thyroid Cytopathology atlas were followed.10

The cytology diagnosis was compared with corresponding histopathology diagnosis wherever surgery was performed and Risk of Malignancy was calculated for each Bethesda category. Sensitivity, Specificity, Positive Predictive Value (PPV) and Negative Predictive Value (NPV) were calculated using histopathology diagnosis as gold standard. For this, Nondiagnostic and Atypia of Undetermined Significance cases were excluded as nondefinitive diagnosis and categories Suspicious for Malignancy and Malignant were together considered as malignant. All the parameters were calculated either excluding Follicular Neoplasm (FN) or including it with either benign or malignant diagnosis to highlight the effect on statistical values.

Results

A total of 300 patients were included in the study. Thyroid fine needle aspirates from these patients were classified according to TBSRTC as Nondiagnostic (ND)- 17 cases (5.67%), Benign- 264 cases (88%), Atypia of Undetermined Significance (AUS)- 1 case (0.33%), Follicular Neoplasm (FN)- 6 cases (2%), Suspicious for malignancy (SFM)- 0 case (0%) and Malignant- 12 cases (4%) (Table 1) (Figure 1,Figure 2).

Benign category was the largest category followed by Nondiagnostic category. Benign follicular nodule was the predominant subcategory followed by chronic lymphocytic thyroiditis. Papillary Thyroid Carcinoma was the most common malignancy reported in our study (Table 1).

All patients were followed for surgery, out of which histopathology diagnosis was available for 32 patients. The Risk of Malignancy for each Bethesda category calculated by comparing cytologic diagnosis with corresponding histopathologic diagnosis is shown in Table 2 . The risk of malignancy for Suspicious for Malignancy category could not be calculated as no case was reported in this category.

Sensitivity, Specificity, Positive Predictive Value (PPV) and Negative Predictive Value (NPV) were 100%, 100%, 100%, 100% (FN excluded); 80%, 100%, 100%, 96% (FN included as benign); 100%, 95.83%, 83.33%, 100% (FN included as malignant) (Table 3).

Table 1

Distribution of cases into various categories and subcategories as per TBSRTC

Bethesda Category Sub-categories Number of cases Percentage (%)
I. Non diagnostic 17 5.67
Cyst fluid only 0 0.00
Virtually acellular specimen 14 4.67
Others (obscuring blood, clotting artifact, etc.) 3 1.00
II. Benign 264 88.00
consistent with a benign follicular nodule (colloid nodule, adenomatoid nodule) 183 61.00
consistent with chronic lymphocytic (Hashimoto) thyroiditis 75 25.00
consistent with granulomatous (subacute) thyroiditis 2 0.67
Other 4 1.33
III. Atypia of Undetermined Significance 1 0.33
IV. Follicular Neoplasm 6 2.00
Follicular Neoplasm 5 1.67
Follicular Neoplasm, Hurthle Cell (Oncocytic) type 1 0.33
V. Suspicious for Malignancy 0 0.00
VI. Malignant 12 4.00
Papillary Thyroid Carcinoma 5 1.67
Poorly differentiated carcinoma 1 0.33
Medullary thyroid carcinoma 2 0.67
Undifferentiated (Anaplastic) carcinoma 3 1.00
Non-Hodgkin Lymphoma 1 0.33
Total 300 100.00

Table 2
Bethesda category Cytology Diagnosis No. of cases with available histopathology diagnosis Histopathology Diagnosis No. of cases which turned out to be malignant Risk of Malignancy (%)
I. Non diagnostic 17 2 Colloid Goitre=1 Metastatic squamous cell carcinoma, thyroid=1 1 50%
II. Benign 264 23 (Colloid Goitre, Nodular Goitre)=21 Follicular Adenoma=2 0 0%
III. Atypia of Undetermined Significance 1 1 Follicular Adenoma=1 0 0%
IV. Follicular Neoplasm 6 2 Colloid Goitre=1 Insular Carcinoma=1 1 50%
V. Suspicious for Malignancy 0 0 0 0 -
VI. Malignant 12 4 Papillary Thyroid Carcinoma=3 Anaplastic Carcinoma=1 4 100%
Total 300 32 32 6 -

Correlation of cytology diagnosis with histopathology diagnosis and calculation of Risk of Malignancy for each Bethesda category

Table 3
Cytology Diagnosis Histopathology Diagnosis Total
Benign Malignant
I. Non diagnostic 1 1 2
II. Benign 23 0 23
III. Atypia of Undetermined Significance 1 0 1
IV. Follicular Neoplasm 1 1 2
V. Suspicious for Malignancy 0 0 0
VI. Malignant 0 4 4
Total 26 6 32

Cytologic - Histopathologic correlation with benign and malignant cases for calculation of Sensitivity, Specificity, PPV and NPV

Figure 1

Photomicrograph from a case of colloid nodule showing abundant colloid with few follicular cells (MGG 40 X).

https://s3-us-west-2.amazonaws.com/typeset-media-server/705b4b93-75d0-4a82-b25a-71ba46835635image1.png

Figure 2

Photomicrograph from a case of AUS showing few clusters as well as singly scattered follicular cells with mild anisonucleosis and focal microfollicle formation (PAP 400 X).

https://s3-us-west-2.amazonaws.com/typeset-media-server/705b4b93-75d0-4a82-b25a-71ba46835635image2.png

Figure 3

Photomicrograph showing Hurthle cells in follicular formations from a case of Follicular Neoplasm, Hurthle Cell Type (MGG 400 X).

https://typeset-prod-media-server.s3.amazonaws.com/article_uploads/11fc2ce9-09cd-4f52-be21-b6beb2d47800/image/78b31b14-ac9f-4c42-97e9-2dfce1b26bc1-ujdpo-20-3.png

Figure 4

Photomicrograph from a case of Papillary Thyroid Carcinoma showing multiple complex papillae with peripheral palisading of the tumor cells (PAP 100 X), inset showing optically clear nuclei with intranuclear grooves (PAP 400 X).

https://typeset-prod-media-server.s3.amazonaws.com/article_uploads/11fc2ce9-09cd-4f52-be21-b6beb2d47800/image/2d3f6cab-952d-44ed-a8fe-57b2463545e7-ujdpo-20-4.png

Figure 5

Photomicrograph from a case of Medullary Thyroid Carcinoma showing clusters as well as singly scattered spindle shaped cells with elongated nuclei (MGG 400 X).

https://typeset-prod-media-server.s3.amazonaws.com/article_uploads/11fc2ce9-09cd-4f52-be21-b6beb2d47800/image/56247951-bda2-440c-922a-967413f8c299-ujdpo-20-5.png

Discussion

TBSRTC has been widely adopted in the United States and in many places worldwide and has been endorsed by the American Thyroid Association.10,11 The distribution of cases into various TBSRTC categories in our study were compared with other studies (Table 4 ).

Table 4
Bethesda category Present study Mondal et al.3 Mehra et al.4 Bhat et al.12 Laishram et al.13 Jo et al.14
I Non diagnostic 5.67 1.2 7.2 6.6 5.2 18.6
II Benign 88 87.5 80 82 89.9 59
III AUS 0.33 1 4.9 2 0 3.4
IV Follicular Neoplasm 2 4.2 2.2 2.5 2.2 9.7
V Suspicious for malignancy 0 1.4 3.6 1.6 0.3 2.3
VI Malignant 4 4.7 2.2 5.1 2.2 7.0

Comparison of percentages of distribution of cases of present study with other studies

The frequency of Non Diagnostic interpretations varies notably from laboratory to laboratory (range, 3-34%).10 The findings of our study (5.67%) are consistent with this range and are comparable with studies by Mehra et al.,4 Bhat et al,12 and Laishram et al.,13 (Table 4). Because most thyroid nodules are benign, a benign result is the most common FNA interpretation (approximately 60-70% of all cases).10 The cases in benign category in our study (88%) are higher than this range and also differ from study by Jo et al.,14 but are comparable with other studies.3,4,12,13 Being the only tertiary care center of our province, it caters to a large number of patients on both direct and referral basis, so a large population representative of general population is encountered that could be a reason for higher number of cases in benign category.

AUS cases reported in our study are comparable with studies by Mondal et al.,3 and Laishram et al.,13 and don't exceed upper limit of 10% as per Bethesda system.10 Follicular Neoplasm cases reported in our study are also similar to other studies.4,12,13 Suspicious for Malignancy (SFM) diagnoses account for approximately 3% (range 1.0-6.3%) of all thyroid FNAs. As with any indeterminate diagnosis, this category should be used judiciously so that patients are managed as appropriately as possible.10 No case was reported under this category in our study. A malignant thyroid FNA diagnosis accounts for approximately 5% (range, 2-16%) of all thyroid FNAs.10 Malignant cases (Category VI) in our study are within this range and are comparable with other studies.3,12

The risk of malignancy for Benign and Malignant categories have corroborated with implied risks mentioned in the Bethesda System,10 and also with other studies available in literature,14,15,16 as shown in Table 5. TBSRTC recommends clinical and sonographic follow-up for Benign category and surgical management for malignant category.10

Table 5
TBSRTC category Risk of Malignancy (%) as per TBSRTC guidelines10 Mondal et al.3 Jo et al.14 Arul et al.15 Yassa et al.16 Present Study
I Non diagnostic 5-10 0 8.9 0 10 50
II Benign 0-3 4.5 11 0.8 0.3 0
III Atypia of Undetermined Significance ~10-30 20 17 24.4 24 0
IV Follicular Neoplam 25-40 30.6 25.4 28.9 28 50
V Suspicious for Malignancy 50-75 75 70 70.8 60 -
VI Malignant 97-99 97.8 98.1 100 97 100

Comparison of Risk of Malignancy in various diagnostic categories of present study with TBSRTC guidelines and other published studies

The implied risk of malignancy as per updated TBSRT C guidelines for lesions in Nondiagnostic category is 5-10%,10 but reported malignancy rates in various studies in literature demonstrate significant variability between 2% and 70.6%.17 TBSRTC recommends repeat aspiration with ultrasound guidance for this category.10 In our study too, malignancy risk for this category is higher (50%) than the range. This could be explained by smaller denominator patients (2cases) with available histopathology diagnosis in this category as a result of which malignancy risk has been overestimated for this category. TBSRTC recommends repeat aspiration for this category which was not performed in one case and other clinical history (lymphadenopathy) or Ultrasound findings may have warranted excision biopsy in this patient after which it was diagnosed as malignant (Table 2).

The risk of malignancy for AUS category is much lower (0%) than the TBSRTC guidelines. This could be explained by lesser cases (only 1 case) reported in this category and this case only underwent surgery and was reported as benign on histopathology. TBSRTC recommends conservative management with repeat FNA or molecular testing in most cases of initial AUS interpretation.10 The risk of malignancy for Follicular Neoplasm category in our study is higher than the TBSRTC guidelines as well as other published studies. Surgical management is recommended for this category supplemented by molecular testing.10

The correlation of cytology and histopathology diagnosis is an important quality assurance method as it allows cytopathologists to calculate their false postive and false negative results.18 Sensitivity, Specificity, Positive Predictive Value (PPV) and Negative Predictive Value (NPV) calculated by cytologic-histopathologic correlation using histopathology diagnosis as gold standard were compared with other studies (Table 6).

Table 6
Studies Criteria Sensitivity (%) Specificity (%) PPV (%) NPV (%)
Mehra et al.4 FN excluded 76.92 88.46 76.92 88.46
FN included as benign 73.33 89.66 78.57 86.67
FN included as malignant 78.57 81.25 64.71 89.66
Kulkarni et al.19 FN excluded 100 100 100 100
FN included as benign 66.7 100 100 92.9
FN included as malignant 75.0 75.0 50.0 90.0
Present study FN excluded 100 100 100 100
FN included as benign 80 100 100 96
FN included as malignant 100 95.83 83.33 100

Comparison of sensitivity, specificity, PPV and NPV of present study with other studie

If FN is included with malignant group, the sensitivity increases but specificity decreases with a decrement in positive predictive value. These findings of our study are consistent with studies by Mehra et al.,4 and Kulkarni et al.,19 (Table 6).

The present study shows that FNAC can be relied upon as an alternative to histopathology since it displays a quite high sensitivity and specificity (80-100%). However, it must be kept in mind that some categories have been rearranged for the purpose of analysis (e.g. higher sensitivity was achieved when FN was excluded and when included with malignant group while higher specificity was achieved when FN was included with benign category).

Conclusion

The findings of our study were consistent with other published studies available in literature. The Bethesda System for Reporting Thyroid Cytopathology has led to clear interpretation of the thyroid FNAC report against the usage of personalized descriptive terminologies for thyroid FNA reporting conventionally being followed in our institution therefore improving communication between pathologists and clinicians. The present study also concludes FNAC to be a sensitive and specific test for preoperative evaluation of thyroid lesions and FNAC using Bethesda guidelines is useful in risk assessment of thyroid nodules thereby guiding appropriate management.

Conflict of Interest

None.

Source of Funding

None.

References

1

A G Unnikrishnan U V Menon Thyroid disorders in India: An epidemiological perspectiveIndian J Endocr Metab2011157881

2

S Agarwal D Jain Thyroid cytology in India: contemporary review and meta-analysisJ Pathol Transl Med201751533547

3

S K Mondal S Sinha B Basak D N Roy S K Sinha The Bethesda system for reporting thyroid fine needle aspirates: A cytologic study with histologic follow-upJ Cytol2013309499

4

P Mehra A K Verma Thyroid cytopathology reporting by the Bethesda system: A two-year prospective study in an academic institutionPatholog Res Int2015Article ID 240505, 11 pages

5

Cga Theoharis K M Schofield L Hammers R Udelsman D C Chhieng The Bethesda thyroid fine-needle aspiration classification system: year 1 at an academic institutionThyroid2009191112151223

6

Z W Baloch V A Livolsi S L Asa J Rosai M J Merino G Randolph Diagnostic terminology and morphologic criteria for cytologic diagnosis of thyroid lesions: a synopsis of the national cancer institute thyroid fine needle aspiration state of the science conferenceDiagn Cytopathol2008366425437

7

L J Layfield E S Cibas H Gharib S J Mandel Thyroid Aspiration Cytology: current statusCA Cancer J Clin20095999110

8

Orell SR, Sterrett GF. Orell & Sterrett's Fine Needle Aspiration Cytology. 5th ed. New Delhi: RELX India Private Limited2012118155

9

E S Cibas S Z Ali The Bethesda System for Reporting Thyroid CytopathologyAm J Clin Pathol2009132658665

10

Ali SZ, Cibas ES, Eds. The Bethesda System for Reporting Thyroid Cytopathology. Definitions, Criteria and Explanatory Notes.2nd ed. Switzerland: Springer2018

11

B R Haugen E K Alexander K C Bible G M Doherty S J Mandel Y E Nikiforov American Thyroid Association Management Guidelines for Adult Patients with Thyroid Nodules and Differentiated Thyroid Cancer: The American Thyroid Association Guidelines Task Force on Thyroid Nodules and Differentiated Thyroid CancerThyroid20162611133

12

S Bhat N Bhat H Bashir S Farooq R Reshi M J Nazeir The Bethesda System for Reporting Thyroid Cytopathology: a two year institutional auditInt J Cur Res Rev201686511

13

R S Laishram T Zothanmawii Z Joute P Yasung K Debnath The Bethesda system of reporting thyroid fine needle aspirates: A 2-year cytologic study in a tertiary care instituteJ Med Soc201731137

14

V Y Jo E B Stelow S M Dustin K Z Hanley Malignancy risk for fine-needle aspiration of thyroid lesions according to the Bethesda System for Reporting Thyroid CytopathologyAm J Clin Pathol2010134450456

15

P Arul C Akshatha S Masilamani A study of malignancy rates in different diagnostic categories of the Bethesda system for reporting thyroid cytopathology: An institutional experienceBiomed J201538517522

16

L Yassa E S Cibas C B Benson M C Frates P M Doubilet A A Gawande Long-term assessment of a multidisciplinary approach to thyroid nodule diagnostic evaluationCancer Cytopathol20071116508516

17

P Gunes S Canberk M Onenerk M Erkan N Gursan E Kilinc A different perspective on evaluating the malignancy rate of non-diagnostic category of the Bethesda system for reporting thyroid cytopathology: A single institute experience and review of the literaturePLoS One2016119162745162745

18

P K Bagga N C Mahajan Fine needle aspiration cytology of thyroid swellings: How useful and accurate is it?Indian J Cancer2010474437442

19

C V Kulkarni M Mittal M Nema R Verma Diagnostic role of the Bethesda system for reporting thyroid cytopathology in an academic institute of Central India: one year experienceIndian J Basic Appl Med Res201652157166
